Rám: Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery with integrated alloy cover, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Vidlice: Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
Hlavové složení: Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Přehazovačka: Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Přesmykač:
Řazení: Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
Brzdové páčky: Sram G2 R, tool-free reach adjust
Brzdy:
Kliky a převodníky: Race Face Aeffect ebike, 165mm
Pedály:
Řídítka: Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Představec: Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Sedlovka: Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
Sedlo: FIZIK Terra Aidon X5 145mm
Náboj přední: Mavic, Boost 15x110mm, IS 6 bolts
Náboj zadní: Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts
Ráfky: Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Pláště: Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead, Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Řetěz: Sram SX Eagle, 12s, Powerlock
Kazeta: Sram PG-1210, 11-50T, 12s
Dráty: Mavic J-bend duble butted, contactless lacing
