Rám: Foxy 29 Stealth Air full Carbon, Zero Suspension System, 150mm travel, Forward Geometry, aluminium CSC upper link with carbon bridge, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. *Optional Geometry Kit
Vidlice: Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload
Hlavové složení: Acros custom for 1-1/2
Přehazovačka: Sram Trigger NX Eagle, 12s, X-Actuation 1:1
Přesmykač:
Řazení: Sram Trigger NX Eagle, 12s, X-Actuation 1:1
Brzdové páčky: Sram G2 R, tool-free reach adjust
Brzdy:
Kliky a převodníky: Truvativ Descendant 6K Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
Pedály:
Řídítka: Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Představec: Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Sedlovka: Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
Sedlo: SDG BEL-AIR 3.0, LPU foam, steel rails
Náboj přední: DT 370, Boost 15x110mm, IS 6 bolts
Náboj zadní: DT 370, Boost 12x148mm, 18T Ratched LN system, IS 6 bolts
Ráfky: DT Swiss E1900 Spline 29, 30mm internal width, sleeved aluminum, tubeless ready, 28 spokes
Pláště: Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead, Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
Řetěz: Sram NX Eagle, 12s, Powerlock
Kazeta: Sram XG-1230, 11-50T, 12s
Dráty: DT Champion, straightpull
